Elastic rubber castor wheels are the solution that guarantees non marking, smooth running and quiet performance. These wheels are best for fragile surfaces and calm environments (where loud noises are not appreciated). For example, environments such as hospitals, commercial spaces and recreational facilities. Additionally, you can also use these wheels in all sorts of machines, transport devices and conveyor belts. Available in different heights and capacities, elastic rubber castor wheels can meet every need. Simply put, no matter the surface on which they run, the wheels can move industrial trolleys and roll containers quickly and conveniently. If you are looking for the best way to add mobility and versatility to your industrial equipment, do not look anywhere else and choose Muvall! We have a wide range of elastic rubber castors, all made from high quality and durable elastic rubber. It means our elastic rubber castors come with exceptional strength and resilience so that you can use them frequently in many applications. The best thing is that whether you need castors to move heavy loads or wheels that can adapt to uneven surfaces and extreme conditions, you will find elastic rubber castor wheels in our selection to suit every need and application.
Product code | Swivel Radius | Wheel Size | Total Height | Plate Size | Stem Height | Hole Pitch | Hole Size | Load Capacity |
---|---|---|---|---|---|---|---|---|
MFTP F 100 50 ELRB | NA | 100x50mm | 142mm | 116x100mm | NA | 85x70mm | 20x13mm | 180Kgs |
MFTP S 100 50 ELRB | 74mm | 100x50mm | 142mm | 116x100mm | NA | 85x70mm | 20x13mm | 180Kgs |
MFTP B 100 50 ELRB | 145mm | 100x50mm | 142mm | 116x100mm | NA | 85x70mm | 20x13mm | 180Kgs |
MFTP F 150 50 ELRB | NA | 150x50mm | 192mm | 116x100mm | NA | 85x70mm | 20x13mm | 230Kgs |
MFTP S 150 50 ELRB | 109mm | 150x50mm | 192mm | 116x100mm | NA | 85x70mm | 20x13mm | 230Kgs |
MFTP B 150 50 ELRB | 145mm | 150x50mm | 192mm | 116x100mm | NA | 85x70mm | 20x13mm | 230Kgs |
Product code | Swivel Radius | Wheel Size | Total Height | Plate Size | Stem Height | Hole Pitch | Hole Size | Load Capacity |
---|---|---|---|---|---|---|---|---|
HDF F 100 50 ELRB | NA | 100x50mm | 158mm | 150x112mm | NA | 120x60mm | 13mm | 180Kgs |
HDF S 100 50 ELRB | 91mm | 100x50mm | 158mm | 150x112mm | NA | 120x60mm | 26x14mm | 180Kgs |
HDF B 100 50 ELRB | 163mm | 100x50mm | 158mm | 150x112mm | NA | 120x60mm | 26x14mm | 180Kgs |
HDF F 150 50 ELRB | NA | 150x50mm | 205mm | 150x112mm | NA | 120x60mm | 13mm | 230Kgs |
HDF S 150 50 ELRB | 155mm | 150x50mm | 205mm | 150x110mm | NA | 120x60mm | 26x14mm | 230Kgs |
MFTP B 150 50 ELRB | 163mm | 150x50mm | 205mm | 150x110mm | NA | 120x60mm | 26x14mm | 230Kgs |
Product code | Swivel Radius | Wheel Size | Total Height | Plate Size | Stem Height | Hole Pitch | Hole Size | Load Capacity |
---|---|---|---|---|---|---|---|---|
PSTIL F 100 50 ELRB | NA | 100x50mm | 140mm | 95x95mm | NA | 70x70mm | 16x11mm | 130Kgs |
PSTIL S 100 50 ELRB | 116mm | 100x50mm | 140mm | 95x95mm | NA | 70x70mm | 16x11mm | 130Kgs |
PSTIL B 100 50 ELRB | 135mm | 100x50mm | 140mm | 95x95mm | NA | 70x70mm | 16x11mm | 130Kgs |
PSTIL F 150 50 ELRB | NA | 150x50mm | 194mm | 115x102mm | NA | 90x64mm | 16x11mm | 150Kgs |
PSTIL S 150 50 ELRB | 116mm | 150x50mm | 194mm | 120x195mm | NA | 90x64mm | 16x11mm | 150Kgs |
PSTIL B 150 50 ELRB | 135mm | 150x50mm | 194mm | 120x95mm | NA | 85x70mm | 20x13mm | 150Kgs |
Elastic rubber castor wheels are specialized wheels that offer a solid rubber tire and inherent elasticity. Besides shock absorption, these wheels offer many other advantages also such as noise reduction and smooth maneuverability. Because of all these advantages, elastic rubber castor wheels are considered as an ideal choice for many applications like medical devices, industrial machinery, carts, etc.
This solid rubber tire that comes with inherent elasticity comes in sizes ranging from 4-6 inches and has a load capacity range of 130-230 kgs. The suitable temperature range is -40° to 80° Celsius and shore hardness is 65 Shore A.
Generally, elastic rubber wheels offer better performance than plastic wheels. That is because in addition to these wheels being more durable and resistant to wear, chemicals and weather conditions, they can also grip various surfaces. That is why many users seeking reliability and longevity rely on elastic rubber castor wheels as their preferred choice compared to rubber wheels.
Ans. No! Solid rubber castors have a softer composition than other hard castors and wheel materials such as metal and plastic. That is why these wheels do not cause any damage or marking on surfaces. However, if you use the wheels on delicate floors like hardwood or laminate for a long period of time, the wheels may cause minor scuffing or indentation. You can use floor protectors or choose soft tread wheels to avoid this situation and minimize any potential damage the wheels may cause over time.
Elastic rubber castor wheels provide flexibility, excellent traction, durability and shock absorption. Due to this, the wheels facilitate effortless and smooth movements in various environments. Moreover, all these qualities of the wheels make them suitable for various applications such as material handling, warehousing and logistics, healthcare, retail and commercial settings, hospitality and catering, automotive industry, industrial environments and institutional and educational facilities.
If you seek to maintain stability and maneuverability, prevent accidents, ensure optimal performance and avoid injuries or equipment damage, remember the below considerations when using elastic rubber wheels:
Yes, all top castor and wheel manufacturers use high quality rubber material when engineering their elastic rubber castors. The material can withstand exposure to various chemicals (oils, solvents, greases and acids) that are commonly found in industries and other outdoor environments. As a result, castor wheels made from high quality rubber material are chemical resistant. And this resistance ensures smooth functioning and longer lifespan of castor wheels in various applications where chemical exposure is usually a concern.
Here is how you can select the ideal elastic rubber castor wheel for your application:
Yes, since elastic rubber wheels have hygienic properties, are made from FDA-approved materials and offer compliance with safety standards, you can safely use them in food and pharmaceutical industries. Moreover, the wheels have smooth surfaces which facilitate easy cleaning and sterilization. This quality further makes the wheels suitable for applications in sensitive environments where cleanliness and contamination control are essential.
You can install elastic castor wheels perfectly and ensure safe and efficient operation if you keep in mind the below mentioned factors:
